MR7 MR9 MR12
|
MR15
|
|
MR7 MR9 MR12
|
|
微型導軌技術支持：樂清市思凱利貿易有限公司，臺灣CPC直線導軌，微型導軌，不銹鋼微型導軌
MR15
|
|
型號規格
|
組裝尺寸
|
軌道尺寸(mm)
|
滑座尺寸(mm)
|
基本額定負荷(N)
|
靜扭矩(Nm)
|
重量
|
|
H
|
W2
|
W1
|
H1
|
P
|
D×d×g1
|
W
|
L
|
L1
|
P1
|
P2
|
Φ
|
E
|
h2
|
M×g2
|
S
|
T
|
C(dyn.)
|
Co(stat.)
|
Mro
|
Mpo
|
Myo
|
Block
g
|
Rail
g/m
|
|
MR 15ML
|
16
|
8.5
|
15
|
9.5
|
40
|
6×3.5×4.5
|
32
|
60
|
44
|
25
|
25
|
2.5
|
3.6
|
12
|
M3×5.5
|
2.8
|
4.3
|
5350
|
9080
|
70
|
26.9
|
26.9
|
90
|
1010
|
|
MR 15MN
|
16
|
8.5
|
15
|
9.5
|
40
|
6×3.5×4.5
|
32
|
43
|
27
|
20
|
25
|
2.5
|
3.6
|
12
|
M3×5.5
|
2.8
|
4.3
|
3810
|
5590
|
43.6
|
10.9
|
10.9
|
53
|
1010
|
|
MR 12ML
|
13
|
7.5
|
12
|
7.5
|
25
|
6×3.5×4.5
|
27
|
47.4
|
34
|
20
|
20
|
2.0
|
-
|
10
|
M3×3.5
|
2.6
|
4.3
|
3240
|
5630
|
34.9
|
16.0
|
16.0
|
51
|
600
|
|
MR 12MN
|
13
|
7.5
|
12
|
7.5
|
25
|
6×3.5×4.5
|
27
|
35.4
|
22
|
15
|
20
|
2.0
|
-
|
10
|
M3×3.5
|
2.6
|
4.3
|
2308
|
3465
|
21.5
|
9.5
|
9.5
|
34
|
600
|
|
MR 9ML
|
10
|
5.5
|
9
|
5.5
|
20
|
6×3.5×4.5
|
20
|
39.5
|
29.5
|
16
|
15
|
1.5
|
-
|
7.8
|
M3×2.8
|
2.2
|
3.3
|
2135
|
3880
|
18.2
|
12.4
|
12.4
|
25
|
330
|
|
MR 9MN
|
10
|
5.5
|
9
|
5.5
|
20
|
6×3.5×4.5
|
20
|
30.5
|
19.5
|
10
|
15
|
1.5
|
-
|
7.8
|
M3×2.8
|
2.2
|
3.3
|
1570
|
2495
|
11.7
|
6.4
|
6.4
|
17
|
330
|
|
MR 7ML
|
8
|
5
|
7
|
4.7
|
15
|
4.2×2.4×2.3
|
17
|
30.4
|
23
|
13
|
12
|
1.2
|
-
|
6.5
|
M2×2.5
|
1.7
|
2.8
|
1310
|
2440
|
9.0
|
7.7
|
7.7
|
16
|
230
|
|
MR 7MN
|
8
|
5
|
7
|
4.7
|
15
|
4.2×2.4×2.3
|
17
|
21.7
|
14.3
|
8
|
12
|
1.2
|
-
|
6.5
|
M2×2.5
|
1.7
|
2.8
|
890
|
1400
|
5.2
|
3.3
|
3.3
|
9
|
230
|
|
MR 5ML
|
6
|
3.5
|
5
|
3.5
|
15
|
3.5×2.4×1
|
12
|
19.5
|
13.5
|
7
|
-
|
0.8
|
-
|
4.5
|
M2.6×2.0
|
1.1
|
2
|
470
|
900
|
2.4
|
2.1
|
2.1
|
3.3
|
120
|
|
MR 5MN
|
6
|
3.5
|
5
|
3.5
|
15
|
3.5×2.4×1
|
12
|
16
|
10
|
-
|
8
|
0.8
|
-
|
4.5
|
M2×1.5
|
1.1
|
2
|
335
|
550
|
1.7
|
1.0
|
1.0
|
3
|
120
|
|
MR 3ML
|
4
|
2.5
|
3
|
2.6
|
10
|
M1.6
|
8
|
16
|
11
|
-
|
5.5
|
-
|
-
|
3.3
|
M2×1.1
|
-
|
1.5
|
295
|
575
|
0.9
|
1.1
|
1.1
|
1.2
|
53
|
|
MR 3MN
|
4
|
2.5
|
3
|
2.6
|
10
|
M1.6
|
8
|
11.7
|
6.7
|
-
|
3.5
|
-
|
-
|
3.3
|
M1.6×1.1
|
-
|
1.5
|
190
|
310
|
0.6
|
0.4
|
0.4
|
0.9
|
53
|
|
|
臺灣CPC微型滑軌MR-MN標準滑塊3-15
